Incoloy - Incoloy Pipe & Tube

Incoloy tubes are a type of high-performance alloy tubing known for their exceptional resistance to corrosion and high-temperature environments. These tubes are primarily composed of nickel, with the addition of various other alloying elements such as chromium, iron, and molybdenum, which impart remarkable properties to the material.

Incoloy tubes are widely used in industries that require robust and reliable tubing solutions, particularly in applications involving aggressive chemicals, extreme temperatures, and harsh environments. These tubes are renowned for their durability and ability to withstand challenging conditions, making them a preferred choice in various sectors, including petrochemical, chemical processing, aerospace, power generation, and more.

Incoloy Pipe & tube size:

Seamless Pipe size: OD: 4 to 219mm; WT: 0.5 to 20mm

Seamless Tube Size: OD: 3.35 mmto 101.6 mm

Welded Pipe size: OD: 5.0 mm to 1219.2 mm

Trade Name	INCOLOY 800	INCOLOY 800H	INCOLOY 800HT	INCOLOY 825
UNS #	N08800	N08810	N08811	N08825
Seamless Pipe / Tube	B/SB407	B/SB407	B/SB407	B/SB423
	A/SA312	A/SA312	A/SA312	B/SB163
	B/SB163	B/SB163	B/SB163
	A/SA213	A/SA213	A/SA213
Welded Pipe / Tube	B/SB515	B/SB515	B/SB515	B/SB705
	B/SB514	B/SB514	A/SA312	B474
	A/SA312/	A/SA312/		B/SB704
	A/SA358	A/SA358
