Inconel - Inconel Pipe & Tube

Our Nickel Alloy Pipes and Tubes products can be offered in seamless, welded and cold drawn form, depending on the alloy you require. Our Seamless Nickel Alloy Pipes and Welded Nickel Alloy tubes size range starts at 1/8" NB or OD size and goes up to 6" NB and OD.



We can offer Nickel Alloy Tubing in random lengths of up to 6 meters long or cut to a specific length as ordered. Nickel pipes and tubes are largely used for piping in the caustic soda, food processing and hydrochloric plants.



Specifications: ASTM B161, B725, B730 / ASME SB161, SB725, B730

Pipe Size: 1/8" To24" in OD & NB in various SWG & SCH

Tube Size:6 mm OD up to 254 mm OD in 0.2 TO 20 mm thickness.

Type: Seamless / Welded / Fabricated / CDW

End: Plain End, Beveled End, Treaded.



Trade Name	UNS #	Seamless Tube	Welded Tube
Alloy 20	N08020	B/SB729	B/SB468
Nickel 200	N02200	B/SB161 B/SB163	B730
Nickel 201	N02201	B/SB161 B/SB163	B730
Monel 400	N04400	B/SB165 B/SB163	B730
Inconel 600	N06600	B/SB167 B/SB163	B/SB516
Inconel 625	N06625	B/SB444	B/SB704
Incoloy 800	N08800	B/SB407 B/SB163 A/SA213	B/SB515
Incoloy 800H	N08810	B/SB407 B/SB163 A/SA213	B/SB515
Incoloy 800HT	N08811	B/SB407 B/SB163 A/SA213	B/SB515
Incoloy 825	N08825	B/SB423 B/SB163	B/SB704
